Microk8s Installation and Configure Dashboard

Microk8s is the most happening thing in Kubernetes World. Here I would like to share my exploration of microk8s. Earlier there was 'Minikube' which is targets to Developers community to reduce the operations.

MicroK8s


Assumption
You know how to create a VM using Vagrant, VirtualBox

Microk8s installation on Ubuntu

To install you should be super user on your Ubuntu VM sudo -i The snap is a package manager available in all Linux distributions. Here in the Ubuntu 18.04 validating is it available. Check snap package tool available
snap version
Now we all set, run the install the microk8s command here the --classic is must
snap install microk8s --classic --edge
Check the version
microk8s.kubectl version --short
Create an alias to simplify your command
alias k="microk8s.kubectl"
Let's use k now
k get nodes
k get nodes -o wide

# check the namespaces list
 k get namespaces
 k get all --all-namespaces
This might take couple of minutes on your laptop that is actually depends on your system capacity and speed. To start the microk8s Duplicate Terminal and try to run a pod. use same aliase here as well. alias k="microk8s.kubectl" on Vagrant user
   sudo usermod -a -G microk8s vagrant
   sudo chown -f -R vagrant ~/.kube

deployment expose k expose deploy nginx --port 80 --target-port 80 type ClusterIP which elinks not installed, so lets install it.
microk8s.start
Once it is installed microk8s we can validate it by inspect option
microk8s.inspect
If there any warnings suggestions goahead and do that. To get all the command options for microk8s
microk8s -h
To get the status of kubenetes cluster
microk8s.status
To get the dashboard
microk8s.enable dashboard dns metrics-server

kubectl get all --namespaces
microk8s kubectl get all -A
kubernetes.service get the ip access in the browser To get the password use admin as user
microk8s.config
To login with Token option on the dashboard need to get the token. microk8s.kubectl -n kube-system get secret |grep kubernetes-dashboard-token microk8s.kubectl -n kube-system describe secrets kubernetes-dashboard-token To terminate your kubernetes cluster on microk8s
microk8s.stop

Deployment to microk8s

microk8s.kubectl create deployment microbot --image=dontrebootme/microbot:v1
microk8s.kubectl scale deployment microbot --replicas=2
For more experiments like this please do watch our YouTube channel


Tuesday, May 12, 2020

Kubernetes (K8s) StatefulSet (sts)

Greetings of the day dear Orchestrator!! In this post, we will discuss exploring the Kubernetes StatefulSet(sts

What is the purpose of Stateful deployment?

Kubernetes' basic unit is Pod, which will be ephemeral in nature and it was designed in such a way that it cannot store the state. To store and maintain the state of the application, Kubernetes introduced a new type of deployment manifestation called it as StatefulSet.



Here in this post, we will be experimenting with the most important deployment model that is StatefulSet which will be interconnected with the multiple storage related objects PersistantVolume(PV) and PersistentVolumeClaim (PVC).

Assumptions

To work on this experiment you must have Kubernetes cluster running on single node or multi-node and it should have a NFS remote storage access that depends on your platform. Here I've EC2 instance having  NFS service configured and run:

Let's define the couple of PV(4) using the NFS server which will be consumed by the PVC. The Stateful deployment is going to have the Pod and PVC template manifestation.

Creating a YAML file for pvc :
apiVersion: v1
kind: PersistentVolume
metadata:
  name: nfs-pv0
spec:
  storageClassName: manual
  capacity:
    storage: 200Mi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteOnce
  mountOptions:
    - hard
    - nfsvers=4.1
  nfs:
    path: /export/volume/pv0
    server: 172.31.46.253
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: nfs-pv1
spec:
  storageClassName: manual
  capacity:
    storage: 200Mi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteOnce
  mountOptions:
    - hard
    - nfsvers=4.1
  nfs:
    path: /export/volume/pv1
    server: 172.31.46.253
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: nfs-pv2
spec:
  storageClassName: manual
  capacity:
    storage: 200Mi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteOnce
  mountOptions:
    - hard
    - nfsvers=4.1
  nfs:
    path: /export/volume/pv2
    server: 172.31.46.253
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: nfs-pv3
spec:
  storageClassName: manual
  capacity:
    storage: 200Mi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteOnce
  mountOptions:
    - hard
    - nfsvers=4.1
  nfs:
    path: /export/volume/pv3
    server: 172.31.46.253
Now, use the following command to create the PVC:
Syntax :
kubectl create -f nfs-pv.yaml
Output :
Checking the PVC are created or not with the simple ls command :
Syntax :
ls
Output :

Using another YAML file for creating PV files :
---
apiVersion: v1
kind: Service
metadata:
  name: nginx
  labels:
    app: nginx
spec:
  ports:
  - port: 80
    name: web
  clusterIP: None
  selector:
    app: nginx
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: web-sts
spec:
  serviceName: "nginx"
  replicas: 4
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: gcr.io/google_containers/nginx-slim:0.8
        ports:
        - containerPort: 80
          name: web-sts
        volumeMounts:
        - name: www
          mountPath: /usr/share/nginx/html
  volumeClaimTemplates:
  - metadata:
      name: www
    spec:
      storageClassName: manual
      accessModes:
        - ReadWriteOnce
      resources:
        requests:
          storage: 100Mi
Now, use the following command to create the PV:
Syntax:
kubectl create -f web-sts.yaml
Output :

Checking the PV are created or not with the following command :

Syntax :
kubectl get pv
Output :

Ready to use Statefulsets now, you can watch all the running terms at one place by using the below command :
Syntax :
watch kubectl get all
Output :




Thursday, May 7, 2020

K8s Storage Volumes part 1 - EmptyDir

Hello, Dear DevOps enthusiasts, In this post, we are going to explore the emptyDir Volume, which is going to work as local data share between containers in a Pod.

I had read the book titled 'Kubernetes in action', from that book I want to understand Persistance Volumes and Persistence Volume Claims in detail. will run the following example for PV that uses emptyDir volume type.

Every new learning is like a game! if you take each trouble as a game level it will be a wonderful game. Once you finish the desired state it's winning the game! why to wait let's jump on this game

Kubernetes emptyDir Volume

Assumptions

  • Docker installed
  • Kubernetes Installed and configured Cluster
  • AWS access to EC2 instances




We need to create a Tomcat container and Logstash container in the Kubernetes pod. In the below diagram, it will share the log file using Kubernetes volume that is empty dir.



The tomcat and Logstash cant use the network via localhost and it will share the filesystem.
Creating a YAML file :

apiVersion: apps/v1
kind: Deployment
metadata:
  name: tomcat
spec:
  replicas: 1
  selector:
    matchLabels:
        run: tomcat
  template:
    metadata:
      labels:
        run: tomcat
    spec:
      containers:
      - image: tomcat
        name: tomcat
        ports:
          - containerPort: 8080
        env:
        - name: UMASK
          value: "0022"
        volumeMounts:
          - mountPath: /usr/local/tomcat/logs
            name: tomcat-log
      - image: docker.elastic.co/logstash/logstash:7.4.2
        name: logstash
        args: ["-e input { file { path => \"/mnt/localhost_access_log.*\" } } output { stdout { codec => rubydebug } elasticsearch { hosts => [\"http://elasticsearch-svc.default.svc.cluster.local:9200\"] } }"]
        volumeMounts:
          - mountPath: /mnt
            name: tomcat-log
      volumes:
        - name: tomcat-log
          emptyDir: {}

Output :


Now, creating the tomcat and logstash pods.
Syntax :
kubectl create -f tomcat-longstash.yaml
Output :
Now, checking the tomcat and logstash pods are ready.
Syntax :
kubectl get pods
Output :


Troubleshooting levels:
We have faced 2 levels of game-changers, when we tried to type the YAML file content it was a lot of indentations which matters a lot if you miss something it throughs error with hint as 'line numbers'. The most interesting thing when we define the two containers one after other, there is 'spec' should be handled properly.

In level 2 it is another adventurous journey, the Logstash image is no longer available in the docker hub. we have tweaked here and there to find what best repo gives this. With the googling reached to the elastic.co where ELK related images are published after replacing of Logstash image name. The second level of game over end entered into next level!


Finally, the last stage of the game, Connecting the logstash container and able to see the /mnt directory which contains logs that are generated from tomcat server. That concludes our experiment is successful.

Syntax :
kubectl exec -it tomcat-646d5446d4-l5tlv -c logstash -- /bin/bash
ls /mnt

Output :

Hence this will conclude that we can define the manifestation for the inter container sharing the storage.

Enjoy this fun-filled learning on Kubernetes! contact us for support and help on the Infrastructure build and delivery.

Wednesday, May 6, 2020

K8s Storage NFS Server on AWS EC2 Instance

Hello DevOps enthuiast, In this psot we would like to explore the options available on Kubernetes Storage and Volume configurations. Especially in AWS environment if we have provisioned the Kubernetes Cluster then how we can use the storage effectively, need to know all the options. In the sequence of learning on 'Kubernetes Storage' experimenting on the NFS server on AWS EC2 instance creation and using it as Persistent Volume. In the later part, we would use the PVC to claim the required space from the available PV. That in turn used inside the Pod as specifying a Volume.

Kubernetes Storage: NFS PV, PVC

Assumptions

  • Assuming that you have AWS Console access to create EC2 instances.
  • Basic awareness of the Docker Container Volumes
  • Understand the need for Persistency requirements

Login to your aws console
Go to EC2 Dashboard, click on the Launch instance button
Step 1: Choose an AMI: "CentOS 7 (x86_64) - with updates HVM" Continue from Marketplace









Step 2: Choose instance type:



Step 3: Add storage: Go with default 1 vCPU, 2.5GHz and Intel Xeon Family, meory 1GB EBS, click 'Next'


Step 5: Add Tags: Enter key as 'Name' and Value as 'NFS_Server'


Step 6: Configure Security Group: select existing security group



Step 7: Review instance Launch: click on 'Launch' button



Select the existing key pair or create new key pair as per your need



 Now Let's use PUTTY terminal login as centos and switch to root user using 'sudo -i'
yum install nfs-utils -y
systemctl enable nfs-server
systemctl start nfs-server
 mkdir /export/volume -p
chmod 777 /export/volume
vi /etc/exports
write the following
  /export/volume *(no_root_squash,rw,sync)
Now save and quit from vi editor and run the following command to update the Filesystem.
  exportfs -r

Confirm the folder name by turning it to green colored by listing the folder.
  ls -ld /export/


Here the NFS volume creation steps completed! ready to use. # Kuernetes PersistentVolume, PersistentVolumeClaim
Create 'nfs-pv.yaml' file as:
apiVersion: v1
kind: PersistentVolume
metadata:
  name: nfs-pv
spec:
  capacity:
    storage: 5Gi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteOnce
  mountOptions:
    - hard
    - nfsvers=4.1
  nfs:
    path: /export/volume
    server: 172.31.8.247

Let's create the PersistentVolume with NFS mounted on separate EC2 instance.
  kubectl create -f nfs-pv.yaml
Check the pv creation successful by kubectl command
  kubectl get pv


Create PersistenceVolumeClaim

Now create a pvc PersistentVolumeClaim with:
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: my-nfs-claim
spec:
  accessModes:
    - ReadWriteOnce
  volumeMode: Filesystem
  resources:
    requests:
      storage: 5Gi

Now use the create subcommand:
  kubectl create -f my-nfs-claim.yaml
Let's validate that PVC created
  kubectl get pvc
Now all set to use a Database deployment inside a pod, let's choose MySQL.
proceed with creating a file with name as mysql-deployment.yaml manifestation file:
apiVersion: apps/v1 # for versions before 1.9.0 use apps/v1beta2
kind: Deployment
metadata:
  name: wordpress-mysql
  labels:
    app: wordpress
spec:
  selector:
    matchLabels:
      app: wordpress
      tier: mysql
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: wordpress
        tier: mysql
    spec:
      containers:
      - image: mysql:5.6
        name: mysql
        env:
        - name: MYSQL_ROOT_PASSWORD
          value: welcome1
        ports:
        - containerPort: 3306
          name: mysql
        volumeMounts:
        - name: mysql-persistent-storage
          mountPath: /var/lib/mysql
      volumes:
      - name: mysql-persistent-storage
        persistentVolumeClaim:
          claimName: my-nfs-claim

Let's create the mysql deployment which will include the pod definitions as well.
kubectl create -f mysql-deployment.yaml
# Check the pod list
kubectl get po -o wide -w
>> Trouble in ContainerCreating take the name of the pod from the previous command.
kubectl logs wordpress-mysql-xx
check nfs mount point shared On the nfs-server ec2 instance
exportfs -r
exportfs -v

Validation of nfs-mount: Using the nfs-server IP mount it on the master node and worker nodes.
mount -t nfs 172.31.8.247:/export/volume /mnt
Example execution:
root@ip-172-31-35-204:/test
# mount -t nfs 172.31.8.247:/export/volume /mnt
mount: /mnt: bad option; for several filesystems (e.g. nfs, cifs) you might need a /sbin/mount.type helper program.
The issue is with nfs on master and cluster verified with:
ls -l /sbin/mount.nfs
Example check it...
root@ip-172-31-35-204:/test# ls -l /sbin/mount.nfs
ls: cannot access '/sbin/mount.nfs': No such file or directory
This confirms that nfs-common not installed on the master node. same thing required on worker nodes aswell. Fix: The client needs nfs-common:
sudo apt-get install nfs-common -y
Now you need th check that mount command works as expected.After confirming mount is working then unmount it.
umount /mnt
Check pod list, where the pod STATUS will be 'Running'.
kubectl get po
SUCCESSFUL!!! As Volume Storage is mounted we can proceed! Let's do the validation NFS volume Enter into the pod and see there is a volume created as per the deployment manifestation.
kubectl exec -it wordpress-mysql-newpod-xy /bin/bash

root@wordpress-mysql-886ff5dfc-qxmvh:/# mysql -u root -p
Enter password:
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 2
Server version: 5.6.48 MySQL Community Server (GPL)

Copyright (c) 2000, 2020, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

create database test_vol;


mysql> create database test_vol;
Query OK, 1 row affected (0.01 sec)

show databases
Test that persistant volume by deleting the pod
kubectl get po
kubectl delete po wordpress-mysql-886ff5dfc-qxmvh
kubectl get po
As it is auto healing applied and new pod will be created, inside the new pod expected to view the volume with
  kubectl exec -it wordpress-mysql-886ff5dfc-tn284 -- /bin/bash
Inside the container now
mysql -u root -p
enter the password
Surely you could see that "test_vol" database accessible and available from this newly created pod.
show databases;
Hence it is proved that the volume used by pod can be reusable even when pod destroyed and recreated.
Go and check the nfs-server mounted path /export/volume you can see the databases created by the mysql database will be visible.

Reference: https://unix.stackexchange.com/questions/65376/nfs-does-not-work-mount-wrong-fs-type-bad-option-bad-superblockx

Categories

Kubernetes (24) Docker (20) git (13) Jenkins (12) AWS (7) Jenkins CI (5) Vagrant (5) K8s (4) VirtualBox (4) CentOS7 (3) docker registry (3) docker-ee (3) ucp (3) Jenkins Automation (2) Jenkins Master Slave (2) Jenkins Project (2) containers (2) create deployment (2) docker EE (2) docker private registry (2) dockers (2) dtr (2) kubeadm (2) kubectl (2) kubelet (2) openssl (2) Alert Manager CLI (1) AlertManager (1) Apache Maven (1) Best DevOps interview questions (1) CentOS (1) Container as a Service (1) DevOps Interview Questions (1) Docker 19 CE on Ubuntu 19.04 (1) Docker Tutorial (1) Docker UCP (1) Docker installation on Ubunutu (1) Docker interview questions (1) Docker on PowerShell (1) Docker on Windows (1) Docker version (1) Docker-ee installation on CentOS (1) DockerHub (1) Features of DTR (1) Fedora (1) Freestyle Project (1) Git Install on CentOS (1) Git Install on Oracle Linux (1) Git Install on RHEL (1) Git Source based installation (1) Git line ending setup (1) Git migration (1) Grafana on Windows (1) Install DTR (1) Install Docker on Windows Server (1) Install Maven on CentOS (1) Issues (1) Jenkins CI server on AWS instance (1) Jenkins First Job (1) Jenkins Installation on CentOS7 (1) Jenkins Master (1) Jenkins automatic build (1) Jenkins installation on Ubuntu 18.04 (1) Jenkins integration with GitHub server (1) Jenkins on AWS Ubuntu (1) Kubernetes Cluster provisioning (1) Kubernetes interview questions (1) Kuberntes Installation (1) Maven (1) Maven installation on Unix (1) Operations interview Questions (1) Oracle Linux (1) Personal access tokens on GitHub (1) Problem in Docker (1) Prometheus (1) Prometheus CLI (1) RHEL (1) SCM (1) SCM Poll (1) SRE interview questions (1) Troubleshooting (1) Uninstall Git (1) Uninstall Git on CentOS7 (1) Universal Control Plane (1) Vagrantfile (1) amtool (1) aws IAM Role (1) aws policy (1) caas (1) chef installation (1) create organization on UCP (1) create team on UCP (1) docker CE (1) docker UCP console (1) docker command line (1) docker commands (1) docker community edition (1) docker container (1) docker editions (1) docker enterprise edition (1) docker enterprise edition deep dive (1) docker for windows (1) docker hub (1) docker installation (1) docker node (1) docker releases (1) docker secure registry (1) docker service (1) docker swarm init (1) docker swarm join (1) docker trusted registry (1) elasticBeanStalk (1) global configurations (1) helm installation issue (1) mvn (1) namespaces (1) promtool (1) service creation (1) slack (1)
